Bekalan Kuasa Terganggu APC Smart-UPS SRT Lithium Ion 1000VA RM 230V Kad Rangkaian - SRTL1000RMXLI-NC apc SRTL1000RMXLI-NC

APC Smart-UPS On-Line, 1000VA, Lithium-ion, Rackmount 3U, 230V, 8x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit SRTL1000RMXLI-NC

Specifications:

Main

• Main Input Voltage: 230 V

• Product or component type: Uninterruptible power supply (UPS)

• Other Input Voltage: 220 V, 240 V

• Main Output Voltage: 230 V

• Other Output Voltage: 220 V, 240 V

• Rated power in W: 900 W

• Rated power in VA: 1000 VA

• Input Connection Type: IEC 60320 C14

• output connection type: 8 IEC 60320 C13

• Number of rack unit: 3U

• Cable length: 1.8 m

• Number of cables: 1

• Provided equipment: CD with software, Communication cable, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card

• Range of product: Smart-UPS On-Line

Batteries & Runtime

• Battery type: Li-Ion (Lithium-Ion)

• Battery voltage: 48 V

• Extended runtime: 1

• Number of battery filled slots: 0

• Number of battery free slots: 0

• Battery recharge time: 6 h

• Battery life: 5…10 year(s)

• Battery charger power: 103 W rated

General

• Number of power module filled slots: 0

• Number of power module free slots: 0

• product web sub-family: Lithium-Ion

• Redundant: No

• UPS type: Double conversion online

Physical

• Colour: Black with silver front bezel

• Height: 8.5 cm

• Width: 43.2 cm

• Depth: 56 cm

• Net weight: 13.7 kg

• Mounting preference: No preference

• Mounting mode: Rack-mounted with kit

• Two post mountable: 0

• USB compatible: Yes

• Mounting position: Horizontal, Vertical

Input

• Input voltage limits: 160...275 V 40% load, 80...150 V

• Network frequency: 40...70 Hz auto-sensing

Output

• Bypass type: Built-in bypass

• Crest factor: 3 : 1

• Harmonic distortion: Less than 2 %

• Maximum configurable power in VA: 1000 VA

• Maximum configurable power in W: 900 W

• Wave type: Sine wave

• Output frequency: 50/60 Hz +/- 3 Hz sync to mains

Conformance

• Product certifications: CE, EAC, RCM, VDE, UK PSTI

• Marking: CE Mark

• Standards: EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018

• Communications & Management

• Emergency power off: Yes

• Free slots: 0

• Preinstalled device: Network management card 3 with environmental monitoring

• Alarm: Audible and visible alarms : prioritized by severity

Surge Protection and Filtering

• Surge energy rate: 340 J

Packing Units

• Unit Type of Package 1: PCE

• Number of Units in Package 1: 1

• Package 1 Height: 24.5 cm

• Package 1 Width: 60 cm

• Package 1 Length: 81 cm

• Package 1 Weight: 21 kg
